Product Description

Heavy-duty work & long-duration endurance

The drone delivers a flight time of 3.5 hours with a 2 kg payload, 2 hours when carrying a 6 kg payload, and 90 minutes under a 10 kg payload.

Quick Assembly

This fixed-wing UAV adopts state-of-the-art quick-release technology for both the airframe and cable connectors, making assembly and disassembly extremely straightforward. For example, a single person can complete the assembly of this VTOL drone within 3 minutes.

Quick Pod Release

This design allows you to flexibly switch between different payloads, such as surveillance cameras, LiDAR and medical supplies.

Wind and Rain Resistant

The airframe and flight speedometer adopt waterproof construction, enabling this VTOL drone to be weatherproof with an IP54 ingress protection rating. As a result, this water-resistant VTOL UAV can perform emergency missions such as search and rescue even in rainy weather.

Excellent Wind Resistance Performance

Powered by high-lift motors with robust output, the electric VTOL aircraft can withstand wind speeds up to 13 meters per second, making it an ideal aerial platform for coastline patrol and surveillance missions.

Beginner-friendly

The LAUNCH ground control software adopted by the VTOL drone is developed for beginners. Therefore, operators with no prior flying experience can easily pilot the drone proficiently.

Non-stop day and night operation

Equipped with onboard aviation lights, the Sky Whale aircraft is highly visible in the air, especially during nighttime flights.

Built-in flight duration & landing assistance

It delivers smooth and safe landings and is equipped with a ranging radar unit.

Onboard ADS-B

It is fitted with an ADS-B device, so its GPS coordinates will be displayed on the air traffic control (ATC) system.

Hot-swappable batteries

Thanks to an additional built-in autopilot backup battery, the drone’s main battery can be replaced without powering down the entire system. This feature is highly beneficial for conducting multiple flight missions consecutively.

No compass calibration required (Differential GPS / DGPS)

Pilots are not required to perform compass calibration on the VTOL drone, which saves considerable time during emergencies. Furthermore, since the compass has been replaced by Differential Global Positioning System (DGPS), this fixed-wing VTOL aircraft is no longer susceptible to surrounding electromagnetic interference (EMI), greatly enhancing its in-flight stability.

Gimbal (Optional)

Equipped with an onboard zoom camera featuring target tracking capability, this reconnaissance VTOL drone is able to follow and monitor targets (both stationary and moving) along scheduled patrol routes.
In addition, target coordinates can be copied and shared with the command center. Once the surveillance mission is completed, the drone will resume its original patrol route automatically.

Monitor target movement status via Ground Control Station (GCS) (Optional)

Pilots may use the LAUNCH GCS to monitor target movement metrics, including real-time updated GPS coordinates, the distance between the target and the drone, as well as the distance from the target to the home position.

Follow Me Mode (Optional)

On certain occasions, the drone launch and landing platform (such as ships or vehicles) needs to move to complete missions. Under such circumstances, the drone must be capable of following the moving platform and landing after finishing its tasks. This function is extremely useful when the VTOL drone carries out surveillance and monitoring missions at sea.

Remote Deployment & Delivery (Optional)

One-click transportation; professional operators required.
Multiple landing points available, ideal for cargo delivery.

VTOL Landing Parachute (Optional)

The parachute is developed to safeguard this VTOL drone in the event of airborne emergencies.

Unlimited video & data traffic (Optional)

The drone is equipped with a 4G/LTE video transmitter, enabling unlimited video and data transmission.

Multi-purpose Aerial Platform

Boasting excellent flight stability and powerful payload capacity for antenna upgrades, the Skywhale VTOL is applicable to mapping, search & rescue, and surveillance operations.

What contents are included?

• 1 × VTOL Fixed-wing Airframe
  4 × Lift Motors
  4 × Electronic Speed Controllers (ESCs) for lift motors
  2 × 26-inch Carbon Fiber Propellers, clockwise & counter-clockwise set
  1 × ESC for fixed-wing motor
  1 × Fixed-wing Motor
  1 × 22-inch CF Propeller (clockwise rotation) for fixed-wing propulsion
  4 × Servo Motors
  1 × CAN Port Airspeed Sensor
  1 × Flight Controller Power Module
  1 × Pixhawk Cube Orange+ Flight Controller with Differential GPS
  1 × TOF (Time-of-Flight Rangefinder)
  1 × Futaba T6K V3S Radio Transmitter
  1 × Aircraft Assembly & Flight Testing Service
  1 × Flight Hard Case
  1 × LAUNCH Ground Control Station Software

Dimensions & Packing Dimensions

Frequently Asked Questions

Q1:How is the warranty of your products?
We offer 6 months warranty after goods recieved.During warranty period,for non-human-induced malfunction, customers send us some videos and photos to analyze and we ship the replacement parts without additional charge.

Q2: What kind of after service can you offer?
About the technical parts we can offer all the datasheets that’s been used in the drones and will guid which battery or parts to use according to actual usage.

Q3: Can you offer pilot training?
Yes, if you don’t have polit who can fly the drone, we can offer onsite training, but the fees will be charged additional.

Q4: How long it takes to produce the products?
For the most popular models, it take about 2 weeks to get a RTF,for special customized one, will take about 1 month.

Q5: Is shipping by sea available?
Shipping by sea it’s a lot cheaper, but due to the recent regulations it can be very complicated and time consuming, we don’t recomend at the moment.By air is more prefered option.
