Product Description

Long Flight Endurance

This electric VTOL drone can fly for 3 hours when equipped with a surveillance camera, and achieve a 2.5-hour flight time carrying a 2-kilogram payload.

Quick Assembly

This fixed-wing UAV adopts cutting-edge quick-release technology on both the main fuselage and cable connectors, enabling extremely easy assembly and stowage. For instance, a single operator can fully assemble the Tianjing Mini VTOL aircraft within just three minutes.

Rapid Release Cargo Compartment

Its design allows you to flexibly switch between various payloads, such as surveillance cameras, LiDAR and mapping cameras.

Wind & Rain Resistant

Thanks to the waterproof design adopted for its airframe and flight speed components, the Tianjing Mini VTOL UAV features weatherproof performance with an IP55 protection rating. Accordingly, this waterproof VTOL drone can carry out emergency missions such as search and rescue even in rainy conditions.

Built-in Antenna

The video antenna bracket will be integrated into the landing gear in subsequent iterations for a more compact and streamlined airframe. In addition, the sensory-aware landing gear design greatly facilitates maintenance and servicing.

Flying Skills

The LAUNCH ground control software designed for VTOL UAVs is specially developed for beginners. Therefore, operators with no prior flying experience can easily pilot the drone.

24/7 uninterrupted operation

The drone is fitted with onboard navigation lights, making it highly visible in the air, especially during nighttime flights. Additionally, the navigation lights can be manually turned on or off via the LAUNCH UAV ground control software.

Landing

Smooth and safe landings, equipped with ranging radar detection device.

Onboard ADS-B

It is equipped with an ADS-B device, so its GPS coordinates will be displayed on the air traffic control system.

GPS

VTOL UAV pilots no longer need to perform compass calibration, which saves substantial time during emergency scenarios. Furthermore, as the magnetic compass is replaced by DGPS, this fixed-wing VTOL aircraft is immune to surrounding Electromagnetic Interference (EMI), greatly enhancing its in-flight stability.

Gimbal (Optional)

Equipped with an onboard zoom camera featuring target tracking capability, this VTOL UAV is able to pursue and monitor both stationary and moving targets along pre-planned regular patrol routes.
Furthermore, target coordinates can be transmitted and shared with the command center. Upon completion of the surveillance mission, the drone will automatically resume its original patrol route.

Monitor Target Movement Status via GCS (Optional)

Pilots can utilize the LAUNCH Ground Control Station (GCS) to monitor target movement conditions, including real-time updated GPS coordinates, the distance between the target and the drone, as well as the distance from the target to the home position.

Follow-Me Mode (Optional)

On occasion, the drone takeoff and landing platform (such as ships or vehicles) has to move to complete missions. In such scenarios, the UAV needs to follow the moving platform and land after finishing its tasks. This function is highly practical for VTOL drones conducting surveillance missions at sea.

Unlimited video & data transmission (Optional)

Fitted with an onboard 4G/LTE video transmitter, the drone supports unrestricted video streaming and data communication.

Multi-Mission Aerial Platform

Boasting outstanding stability and a large payload capacity for antenna mounting, the Sky Whale Mini VTOL is applicable to mapping, search & rescue, surveillance and other missions.

Dimensions

What is included

• 1 × VTOL Fixed-wing Airframe
  4 × Elevator Motors
  4 × ESCs for elevator motors
  2 × 22-inch Carbon Fiber Propellers, standard CW/CCW set
  1 × ESC for fixed-wing motor
  1 × Fixed-wing Motor
  1 × 18-inch CF Propeller (Clockwise Rotation) for fixed-wing propulsion
  4 × Servo Motors
  1 × CAN Interface Airspeed Indicator
  1 × Flight Controller Power Module
  1 × Pixhawk Cube Orange+ Flight Controller with Differential GPS (DGPS)
  1 × TOF Rangefinder
  1 × Futaba T6K V3S Radio Transmitter
  1 × Aircraft Assembly & Flight Commissioning Service
  1 × Flight Transport Case
  1 × LAUNCH Ground Control Station Software

Frequently Asked Questions

Q1:How is the warranty of your products?
We offer 6 months warranty after goods recieved.During warranty period,for non-human-induced malfunction, customers send us some videos and photos to analyze and we ship the replacement parts without additional charge.

Q2: What kind of after service can you offer?
About the technical parts we can offer all the datasheets that’s been used in the drones and will guid which battery or parts to use according to actual usage.

Q3: Can you offer pilot training?
Yes, if you don’t have polit who can fly the drone, we can offer onsite training, but the fees will be charged additional.

Q4: How long it takes to produce the products?
For the most popular models, it take about 2 weeks to get a RTF,for special customized one, will take about 1 month.

Q5: Is shipping by sea available?
Shipping by sea it’s a lot cheaper, but due to the recent regulations it can be very complicated and time consuming, we don’t recomend at the moment.By air is more prefered option.
