Product Description
| Frequency range | L band, S band, L+S band |
| Networking scale | 32 nodes |
| RF bandwidth | 5/10/20/30MHz optional |
| Networking mode | TDMA adaptive |
| Broadband service | Image rate 2 channels @2Mbps/channel, the whole network sharing ≥30Mbps |
| Carrier modulation | TDD OFDM |
| Multi-hop transmission | >9 hops |
| Operating voltage | DC+4.5V~+17V, typical value +5V |
| Networking time | ≤1s |
| RF channel | 2*Tx 2*Rx |
| Route update | ≤1s |
| Transmit power | 2*0.2W |
| Product power consumption | ≤10W |
| Air-to-ground distance | ≥10km |
| Ranging capability | Support inter-machine ranging |
| Encryption standard | AES 128bit; physical layer encryption |
| Operating temperature | -40℃~+55℃ (customizable) |
| Product size | 65mm*48mm*10mm |
| Complete weight | ≤45g |
| Communication interface | Support 1 100M Ethernet port, 1 RS232 interface, 1 RS422 interface, 1 TTL interface |
