20~40km VTX VRX FPV Wireless Video Transmitter 550MHz 8 Channels DIY Model Number Long Range RC for Drone Silicone Receiver
Original price was: 120.00$.100.00$Current price is: 100.00$.
Product Description
500Mhz VTX Specification:
| Model number: | KP-500TX4W |
| Voltage | DC 12V |
| Current | 700mA |
| Modulation | FM |
| Frequency | 500Mhz~600Mhz optional |
| Channels | 8 channels |
| Frequency band (choose one series) |
500Mhz: (460Mhz, 490Mhz, 500Mhz, 520Mhz, 540Mhz, 560Mhz, 580Mhz, 600Mhz) |
| Transmit Power | 4 watt |
| Video Output | 1 Vp-p(FM) |
| Temperature | -10℃ ~ +50℃ |
| Antenna port | SMA |
| Transmitter Weight | 83g |
| Dimensions | 64*46*20mm |
VRX Specification:
| Model number: | KP-RX500 |
| Voltage | DC 12V |
| Receiving sensitivity | -85dB |
| Modulation | FM |
| Frequency |
500Mhz~600Mhz |
| Channels | 8 channels |
| Frequency band (choose one series) | 500Mhz: (460Mhz, 490Mhz, 500Mhz, 520Mhz, 540Mhz, 560Mhz, 580Mhz, 600Mhz)
|
| Video Output | 1 Vp-p(FM) |
| Temperature | -10℃ ~ +50℃ |
| Antenna port | SMA |
| Transmitter Weight | 83g |
| Dimensions (L * W * H) |
83*46*15mm |
